Omschrijving
BLOCK - GNC24-15 - Linear Power Supply, Open Frame, ITE, 1 Outputs, 360 W, 24 V, 15 A
- No. of Outputs: 1Outputs
- Output Power Max: 360W
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 15A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Input Voltage VAC: 230V AC to 400V AC
- Product Range: -
- Power Supply Output Type: Fixed
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- SVHC: No SVHC (12-Jan-2017)
- Approval Bodies: UL, VDE
- External Depth: 149mm
- External Length / Height: 200mm
- External Width: 150mm
- Frequency Max: 60Hz
- Frequency Min: 50Hz
- Height: 200mm
- Input Voltage: 400VAC
- Input Voltage AC Max: 400V
- Input Voltage AC Min: 230V
- Input Voltage Max: 400VAC
- Input Voltage Min: 230VAC
- Length: 149mm
- Operating Temperature Max: 60°C
- Output Ripple and Noise Voltage pk-pk: 3 %
- Power Supply Type: Linear
- Safety Category: Class I
- Supply Voltage: 230V
- Supply Voltage Max: 400V
- Supply Voltage Min: 230V
- Supply Voltage Typ: 230V AC, 400V AC
- Weight: 8.3kg
- Width: 160mm
