HWS300-24 PSU, Enclosed, 24V, 14A, 336W TDK-Lambda

TDK-LAMBDASKU:HWS300-24 Bestelcode:1456496

Prijs:
Actie prijs€518,43

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (5 units)

Documenten en downloads

Omschrijving

TDK-LAMBDA - HWS300-24 - AC/DC Enclosed Power Supply (PSU), ITE, 1 Outputs, 336 W, 24 V, 14 A

  • No. of Outputs: 1Outputs
  • Output Power Max: 336W
  • Output Voltage - Output 1: 24V
  • Output Current - Output 1: 14A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Output Voltage - Output 4: -
  • Current, Output 4: -
  • Input Voltage VAC: 85V AC to 265V AC
  • Power Supply Output Type: Adjustable, Fixed
  • Product Range: HWS Series
  • SVHC: No SVHC (15-Jan-2018)
  • Applications: Industrial, Lighting, Telecom
  • Approval Bodies: CE, CSA, EN, UL
  • Efficiency: 85%
  • External Depth: 165mm
  • External Length / Height: 82mm
  • External Width: 61mm
  • Height: 82mm
  • Input Voltage AC Max: 265V
  • Input Voltage AC Min: 85V
  • Inrush Current: 40A
  • Length: 165mm
  • Line Regulation: 96mV
  • Load Regulation: 144mV
  • No. of Outputs: 1 Output
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -10°C
  • Output Current Max: 14A
  • Output Ripple Voltage pk-pk: 150mV
  • Output Voltage Max: 28.8V
  • Output Voltage Min: 19.2V
  • Power Rating: 336W
  • Power Supply Type: Switch Mode
