IRR7Z222 Switch, NC/NO, Round, Black, IP67 Apem

APEMSKU:IRR7Z222 Bestelcode:1714209

Prijs:
Actie prijs€42,47

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (34 units)

Documenten en downloads

Omschrijving

APEM - IRR7Z222 - Industrial Pushbutton Switch, IR, 16.2 mm, SPST-NO, SPST-NC, Momentary, Round, Black

  • Switch Operation: Momentary
  • Contact Configuration: SPST-NO, SPST-NC
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: -
  • Contact Current Max: 5A
  • Switch Terminals: Quick Connect, Solder
  • Product Range: IR Series
  • SVHC: No SVHC (15-Jan-2018)
  • Actuation Type: Round
  • Actuator / Cap Colour: Black
  • Contact Current AC Max: 5A
  • Contact Resistance: 100mohm
  • Contact Voltage VAC: 250V
  • Dielectric Strength VDC: 750V
  • IP Rating: IP67
  • Illumination Colour: Non-illuminated
  • Insulation Resistance: 1Gohm
  • No. of Electrical Operations: 500000
  • No. of Mechanical Operations: 1000000
  • Operating Force Max: 5N
  • Operating Force Min: 2N
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Panel Cutout Diameter: 16.2mm
  • Panel Thickness: 3mm
  • Pushbutton Actuator Style: Round
  • Pushbutton Switch Type: Industrial
  • Switch Mounting: Panel
  • Travel: 1.7mm
