XP POWER - JCP4012S3V3 - Isolated Through Hole DC/DC Converter, Metal Case, ITE, 2:1, 40 W, 1 Output, 3.3 V, 10 A
- No. of Outputs: 1 Output
- Output Power Max: 40W
- Output Voltage - Output 1: 3.3V
- Output Current - Output 1: 10A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 18V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 50.8mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 87%
- External Depth: 10.2mm
- External Length / Height: 50.8mm
- External Width: 29.2mm
- Isolation Voltage: 1.5kV
- No. of Outputs: 1Outputs
- Off Load Current: 200mA
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Output Ripple Voltage pk-pk: 50mV
- Power Rating: 40W
- Supply Voltage: 12V
