MULTICOMP PRO - LBDI253P - Switch Disconnector, Interlock, 3 Pole, 690 V, 25 A, IP65, Screw
- No. of Poles: 3 Pole
- Contact Voltage AC Max: 690V
- Contact Current AC Max: 25A
- Approvals / Standards: CSA, EN, IEC, UL
- IP Rating: IP65
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
- Current Rating: 25A
- External Depth: 85mm
- External Length / Height: 87mm
- External Width: 68mm
- Length: 280mm
- Operating Current: 20A
- Power Rating: 11kW
- Proof Voltage: 6kV
- Shaft Diameter: 8mm
- Switching AC3 Power Max: 7.5kW
- Voltage Rating: 690V
