LFSPXO009585 Crystal Oscillator, SMD, 12MHz IQD Frequency Products

IQD FREQUENCY PRODUCTS - LFSPXO009585 - Oscillator, Crystal, 12 MHz, 50 ppm, SMD, 5mm x 3.2mm, 3.3 V, CFPS-69 Series

• Frequency Nom: 12MHz
• Frequency Stability + / -: 50ppm
• Oscillator Case: SMD, 5mm x 3.2mm
• Supply Voltage Nom: 3.3V
• Product Range: CFPS-69 Series
• Operating Temperature Min: -40°C
• Operating Temperature Max: 85°C
• Oscillator Output Compatibility: CMOS
• SVHC: No SVHC (15-Jan-2018)
• Crystal Case: CFPS-69
• Fall Time tf: 12ns
• Frequency: 12MHz
• Frequency Accuracy + @: 50ppm
• Frequency Accuracy - @: 50ppm
• Frequency Stability: ± 50ppm
• Load Capacitance: 15pF
• No. of Pins: 4Pins
• Operating Temperature Range: -40°C to +85°C
• Output Frequency: 12MHz
• Resonator Case: SMD
• Rise Time: 12ns
• Supply Current Max: 2.5mA
• Temperature Stabilty: ± 50ppm
• Type: SPXO
