Omschrijving
AMS OSRAM GROUP - LR G6SP-CBEA-1-1 - High Brightness LED, Advanced Power TOPLED Series, Red, 629 nm, 120 °, 19 lm, 200 mA
- Product Range: Advanced Power TOPLED Series
- LED Colour: Red
- Wavelength Typ: 629nm
- Viewing Angle: 120°
- Luminous Flux @ Test: 19lm
- Forward Current If Max: 200mA
- Forward Current @ Test: 140mA
- Forward Voltage @ Test: 2.1V
- Luminous Intensity @ Test: 7.1cd
- Power Dissipation Pd: 560mW
- Automotive Qualification Standard: -
- MSL: MSL 2 - 1 year
- SVHC: No SVHC (17-Dec-2015)
- Forward Current If: 200mA
- Forward Voltage: 2.1V
- Forward Voltage VF Max: 2.65V
- LED Mounting: SMD
- LED Type: Standard
- Lens Colour: Clear
- Lens Shape: Round with Flat Top
- Luminous Intensity Max: 7100mcd
- Luminous Intensity Min: 2800mcd
- No. of Pins: 6Pins
- Operating Temperature Max: 110°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +110°C
- Opto Case Style: SMD-6, J-Lead, Exposed Pad
- Peak Pulse Current Ippm: 1A
- Peak Wavelength: 632nm
- Power @ Test: 0.3W
- Voltage Vf Min: 1.9V
- Voltage Vf Typ: 2.1V
