Omschrijving
VISHAY - MAL210128104E3 - Electrolytic Capacitor, Screw, 0.1 F, 63 V, ± 20%, Screw, 15000 hours @ 85°C
- Capacitance: 0.1F
- Voltage Rating: 63V
- Product Range: 101 PHR-ST Series
- Lifetime @ Temperature: 15000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Screw
- Diameter: 76mm
- Lead Spacing: 31.8mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 146mm
- ESR: 0.005ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 5A
- AC Ripple Current @ 20kHz: 5A
- Capacitance Tolerance ±: ± 20%
- Capacitor Mounting: Panel
- Climatic Category: 40/085/86
- External Length / Height: 146mm
- Leakage Current: 12.6mA
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Operating life Time: 15000h
- Ripple Current AC: 5A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 85°C
- Tolerance +: 0.2%
- Tolerance -: 0.2%
- Voltage Rating DC Max: 63V
- Voltage Rating V DC: 63V
