VISHAY - MAL210619103E3 - Electrolytic Capacitor, Screw, 10000 µF, 100 V, -10%, +30%, Screw, 20000 hours @ 85°C
- Capacitance: 10000µF
- Voltage Rating: 100V
- Product Range: 106 PED-ST Series
- Lifetime @ Temperature: 20000 hours @ 85°C
- Capacitance Tolerance: +30%, -10%
- Capacitor Terminals: Screw
- Diameter: 65mm
- Lead Spacing: 28.5mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 105mm
- ESR: 0.011ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 11A
- AC Ripple Current @ 20kHz: 11A
- Capacitance Tolerance ±: +30%, -10%
- Capacitor Mounting: Panel
- Climatic Category: 40/085/56
- External Length / Height: 105mm
- Leakage Current: 2µA
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Operating life Time: 20000h
- Ripple Current AC: 11A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 85°C
- Tolerance +: 0.3%
- Tolerance -: 0.1%
- Voltage Rating DC Max: 100V
- Voltage Rating V DC: 100V
