IMO PRECISION CONTROLS - MC14N-S-10110AC - Contactor, 14 A, DIN Rail, 110 VAC, 1NO, 3 Pole, 5.5 kW
- Load Current Inductive: 14A
- Relay Mounting: DIN Rail
- Operating Voltage: 110VAC
- Contact Configuration: 1NO
- No. of Poles: 3 Pole
- Switching Power AC3: 5.5kW
- Switching Current AC1: 25A
- Coil Voltage VAC Nom: 110V
- Coil Voltage VDC Nom: -
- Switching Power AC1: 7.5kW
- Load Current Resistive: 25A
- Switching Current AC3: 14A
- Product Range: MC Series
- SVHC: No SVHC (07-Jul-2017)
- Approval Bodies: cUL
- Approval Category: UL Recognised
- Coil Holding Power: 10VA
- Coil Operating Lower Percent Limit: 85%
- Coil Operating Upper Percent Limit: 110%
- Coil Pull-in Power: 45VA
- External Depth: 65mm
- External Length / Height: 65mm
- External Width: 45mm
- Main Contact Current AC1 Max: 25A
- Main Contact Current AC3 Max: 14A
- Operating Temperature Max: 60°C
- Operating Temperature Min: -40°C
- Output Voltage Max: 690V
- Relay Type: Contactor
