Omschrijving
MULTICOMP PRO - MC34743 - Pin Header, Board-to-Board, 2.54 mm, 1 Rows, 24 Contacts, Through Hole, MC34
- Pitch Spacing: 2.54mm
- No. of Contacts: 24Contacts
- Gender: Header
- Product Range: MC34 Series
- Contact Termination Type: Through Hole
- No. of Rows: 1Rows
- Contact Plating: Gold Plated Contacts
- Contact Material: Copper Alloy
- SVHC: No SVHC (15-Jan-2019)
- Contact Resistance: 20mohm
- Contact Termination: Through Hole Vertical
- Current Rating: 3A
- Flammability Rating: UL94V-0
- Insulation Resistance: 1000Mohm
- Lead Spacing: 2.54mm
- Operating Temperature Max: 105°C
- Operating Temperature Min: -40°C
- Termination Method: Solder
- Voltage Rating VAC: 250V
- Withstand Voltage: 600V
