MULTICOMP PRO - MCCB1C335M2ACB - Tantalum Capacitor, Epoxy-Coated, 3.3 µF, 16 V, ± 20%, PC Pin, 5.1 mm, 10 ohm
- Capacitance: 3.3µF
- Voltage Rating: 16V
- Product Range: MCCB Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 5.1mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 125°C
- ESR: 10ohm
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 20%
- External Depth: 4.2mm
- External Length / Height: 7mm
- External Width: 4.5mm
- Height: 7mm
- Lead Diameter: 0.5mm
- Leakage Current: 0.5µA
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +125°C
