Omschrijving
MULTICOMP PRO - MCHP06W2F100KT5E - SMD Chip Resistor, 1 ohm, ± 1%, 500 mW, 1206 [3216 Metric], Thick Film, High Power
- Resistor Case Style: 1206 [3216 Metric]
- Resistance: 1ohm
- Product Range: HP06 Series
- Voltage Rating: 200V
- Resistor Element Material: Thick Film
- Power Rating: 500mW
- Resistance Tolerance: ± 1%
- Temperature Coefficient: ± 200ppm/°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 0.55mm
- External Length / Height: 3.1mm
- External Width: 1.55mm
- Height: 3.1mm
- No. of Pins: 2Pins
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +155°C
- Resistor Mounting: Surface Mount Device
