Omschrijving
MULTICOMP PRO - MCRH100V227M16X26 - Electrolytic Capacitor, 220 µF, 100 V, ± 20%, Radial Leaded, 2000 hours @ 105°C, Polar
- Capacitance: 220µF
- Voltage Rating: 100V
- Product Range: MCRH Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 16mm
- Lead Spacing: 7.5mm
- Height: 26mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 2000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 26mm
- Lead Diameter: 0.8mm
- Leakage Current: 660µA
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 2000h
- Ripple Current AC: 665mA
- Ripple Current Frequency: 120Hz
- Ripple Current Temperature: 85°C
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 100V
