MULTICOMP PRO - MCTAEF-25R-V - Tactile Switch, MCTAEF, Top Actuated, Surface Mount, Round Button, 300 gf, 50mA at 12VDC
- Product Range: MCTAEF Series
- Actuator Orientation: Top Actuated
- Switch Mounting: SMD
- Actuator Style: Round Button
- Actuating Force: 300gf
- Contact Rating: 50mA at 12VDC
- Switch Dimensions (L x W): 6mm x 3.8mm
- IP Rating: -
- Illumination: Non Illuminated
- SVHC: No SVHC (15-Jan-2019)
- Actuation Type: Top
- Contact Configuration: SPST-NO
- Contact Current Max: 25mA
- Contact Voltage DC Nom: 24V
- External Depth: 3.8mm
- External Length / Height: 7.3mm
- Height: 1.7mm
- Operating Force: 200gf
- Pre-travel: 0.35mm
- Switch Terminals: Solder
