MINISMDC110F-2 PolySwitch, SMD, 1.1A LITTELFUSE

LITTELFUSESKU:MINISMDC110F-2 Bestelcode:1175842

Prijs:
Actie prijs€0,63

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1579 units)

Documenten en downloads

Omschrijving

LITTELFUSE - MINISMDC110F-2 - Resettable Fuse, PPTC, 1812 (4532 Metric), PolySwitch miniSMDC, 8 VDC, 1.1 A, 2.2 A, 0.3 s

  • Thermistor Mounting: SMD
  • Product Range: PolySwitch miniSMDC Series
  • Holding Current: 1.1A
  • Tripping Current: 2.2A
  • Voltage Rating: 8VDC
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jun-2015)
  • Approval Bodies: CSA, TUV
  • Approval Category: UL Recognised
  • Carrying Current Max: 100A
  • External Depth: 0.62mm
  • External Length / Height: 4.73mm
  • External Width: 3.41mm
  • Holding Current Max Ih: 1.1A
  • Initial Resistance Max: 0.21ohm
  • Initial Resistance Min: 0.04ohm
  • Interrupt Current Max: 100A
  • Operating Voltage: 8V
  • PTC Fuse Case Style: 1812 [4532 Metric]
  • Surface Tripped Temperature Max: 125°C
  • Tab Width: 0.25mm
  • Termination Type: Surface Mount Device
  • Thermistor Type: PTC Resettable Fuse
