MULTICOMP PRO - MOR07WJ0102B09 - Through Hole Resistor, 1 kohm, MOR, 7 W, ± 5%, Axial Leaded, 750 V
- Resistance: 1kohm
- Product Range: MOR Series
- Power Rating: 7W
- Resistance Tolerance: ± 5%
- Resistor Case Style: Axial Leaded
- Voltage Rating: 750V
- Resistor Element Material: Metal Oxide
- Temperature Coefficient: ± 350ppm/°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- External Length / Height: 32mm
- No. of Pins: 2Pins
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +155°C
- Resistor Mounting: Through Hole
- Temperature Coeff. +: 350ppm/°C
- Temperature Coeff. -: 350ppm/°C
- Tolerance +: 5%
- Tolerance -: 5%
- Voltage Rating V DC: 750V
