MPI002/Term/AM Switch, Illum Amber Bulgin Limited

BULGIN LIMITED - MPI002/TERM/AM - Vandal Resistant Switch, MPI002, 19.2 mm, SPST-NO, Momentary, Flush, Natural

• Contact Configuration: SPST-NO
• Actuator / Cap Colour: Natural
• Product Range: MPI002 Series
• Switch Operation: Momentary
• Illumination Colour: Amber
• Switch Terminals: Screw
• Contact Current Max: 50mA
• Contact Voltage AC Max: -
• Operating Force: 12N
• Contact Voltage DC Max: 24V
• SVHC: No SVHC (27-Jun-2018)
• Bezel Diameter: 22mm
• Colour: Amber
• Contact Current DC Max: 50mA
• Contact Current Rating: 50mA
• Contact Resistance: 100mohm
• Contact Voltage VDC: 24V
• External Depth: 28.2mm
• External Length / Height: 31mm
• Forward Voltage: 2V
• IP / NEMA Rating: IP66
• IP Rating: IP66
• Insulation Resistance: 1000Mohm
• Luminous Intensity Typ: 220mcd
• Operating Temperature Max: 70°C
• Operating Temperature Min: -30°C
• Panel Cutout Diameter: 19.2mm
• Pushbutton Actuator Style: Flush
• Pushbutton Switch Type: Anti-Vandal
• Switch Mounting: Panel
