COILCRAFT Power Inductors - SMD MSS1246T-153MLC INDUCTOR, 15UH, 3.4A, 20%, PWR, 22MHZ COILCRAFT 2288395 MSS1246T-153MLC
Ga met de muis over de afbeelding om in te zoomen Klik op de afbeelding om in te zomen
COILCRAFT Power Inductors - SMD MSS1246T-153MLC INDUCTOR, 15UH, 3.4A, 20%, PWR, 22MHZ COILCRAFT 2288395 MSS1246T-153MLC

MSS1246T-153MLC INDUCTOR, 15UH, 3.4A, 20%, PWR, 22MHZ COILCRAFT

COILCRAFTSKU:MSS1246T-153MLC Bestelcode:2288395
Prijs:
€3,13

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Uitverkocht

Documenten en downloads

Omschrijving

COILCRAFT - MSS1246T-153MLC - Power Inductor (SMD), 15 µH, 3.4 A, Shielded, 4.68 A, MSS1246T, 12mm x 12mm x 4.6mm

  • Inductance: 15µH
  • RMS Current (Irms): 3.4A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 4.68A
  • Product Range: MSS1246T Series
  • Power Inductor Case: 12mm x 12mm x 4.6mm
  • DC Resistance Max: 0.0541ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 22MHz
