COILCRAFT - MSS1260-105KLD - Power Inductor (SMD), 1 mH, 680 mA, Shielded, 600 mA, MSS1260, 12.3mm x 12.3mm x 6mm
- Inductance: 1mH
- RMS Current (Irms): 680mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 600mA
- Product Range: MSS1260 Series
- Power Inductor Case: 12.3mm x 12.3mm x 6mm
- DC Resistance Max: 1.335ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 2MHz
