MSS1260T-822MLD INDUCTOR, 8.2UH, 4.8A, 20%, PWR, 26MHZ COILCRAFT

COILCRAFTSKU:MSS1260T-822MLD Bestelcode:2288460

Prijs:
Actie prijs€4,38

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Uitverkocht

Documenten en downloads

Omschrijving

COILCRAFT - MSS1260T-822MLD - Power Inductor (SMD), 8.2 µH, 4.8 A, Shielded, 6.44 A, MSS1260T, 12.3mm x 12.3mm x 6mm

  • Inductance: 8.2µH
  • RMS Current (Irms): 4.8A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 6.44A
  • Product Range: MSS1260T Series
  • Power Inductor Case: 12.3mm x 12.3mm x 6mm
  • DC Resistance Max: 0.02ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 26MHz
