MSS1278-103MLD INDUCTOR, 10UH, 5.7A, 20%, PWR, 17MHZ COILCRAFT

COILCRAFTSKU:MSS1278-103MLD Bestelcode:2288499

Prijs:
Actie prijs€3,05

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (470 units)

Documenten en downloads

Omschrijving

COILCRAFT - MSS1278-103MLD - Power Inductor (SMD), 10 µH, 5.7 A, Shielded, 9.36 A, MSS1278, 12.3mm x 12.3mm x 8.05mm

  • Inductance: 10µH
  • RMS Current (Irms): 5.7A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 9.36A
  • Product Range: MSS1278 Series
  • Power Inductor Case: 12.3mm x 12.3mm x 8.05mm
  • DC Resistance Max: 0.0243ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 17MHz
