MSS5131-223MLC Inductor, 22UH, 1.3a, 20%, Pwr, 22MHZ COILCRAFT

COILCRAFTSKU:MSS5131-223MLC Bestelcode:2288611

Prijs:
Actie prijs€4,11

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (83 units)

Documenten en downloads

Omschrijving

COILCRAFT - MSS5131-223MLC - Power Inductor (SMD), 22 µH, 1.3 A, Shielded, 540 mA, MSS5131

  • Inductance: 22µH
  • RMS Current (Irms): 1.3A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 540mA
  • Product Range: MSS5131 Series
  • Power Inductor Case: 5.1mm x 5.1mm x 3.1mm
  • DC Resistance Max: 0.145ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 22MHz
