COILCRAFT - MSS6132-822MLC - Power Inductor (SMD), 8.2 µH, 2.65 A, Shielded, 1.78 A, MSS6132, 6.1mm x 6.1mm x 3.2mm
- Inductance: 8.2µH
- RMS Current (Irms): 2.65A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.78A
- Product Range: MSS6132 Series
- Power Inductor Case: 6.1mm x 6.1mm x 3.2mm
- DC Resistance Max: 0.055ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Reel Quantity: 500
- Self Resonant Frequency Min: 45MHz
