MT2-C93418 Relay, Signal, DPDT, 250VAC, 220VDC, 2A Te Connectivity

TE CONNECTIVITYSKU:MT2-C93418 Bestelcode:9913688

Prijs:
Actie prijs€7,29

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1768 units)

Documenten en downloads

Omschrijving

TE CONNECTIVITY - MT2-C93418 - Signal Relay, 12 VDC, DPDT, 2 A, MT2, Through Hole, Non Latching

  • Coil Voltage: 12VDC
  • Contact Configuration: DPDT
  • Contact Current: 2A
  • Product Range: MT2 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: 250V
  • Contact Voltage VDC: 220V
  • Contact Material: Silver Nickel
  • Coil Resistance: 720ohm
  • Approval Category: UL Recognised
  • Coil Power Continuous: 200mW
  • Coil Voltage VDC Nom: 12V
  • Contact Current AC Max: 2A
  • Contact Current Max: 2A
  • Contact Resistance: 70mohm
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 220V
  • Contact Voltage DC Nom: 220V
  • Current Rating: 2A
  • DC Coil Power: 200mW
  • Dielectric Voltage Coil to Contact: 1050VAC
  • Dielectric Voltage Contact to Contact: 750VAC
  • External Depth: 10mm
  • External Height: 11mm
  • External Length / Height: 11mm
  • External Width: 20.2mm
  • IP / NEMA Rating: IP67
  • Mechanical Life: 5 x 10? operations
  • No. of Pins: 8Pins
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -55°C
  • Operating Time: 4ms
  • PCB Hole Diameter: 0.8mm
