OEG - TE CONNECTIVITY - 5-1419128-0 - General Purpose Relay, OJE Series, Power, Non Latching, SPST-NO, 12 VDC, 8 A
- Contact Configuration: SPST-NO
- Coil Voltage: 12VDC
- Contact Current: 8A
- Product Range: OJE Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 30VDC
- Contact Material: Silver Cadmium Oxide
- Coil Resistance: 720ohm
- SVHC: No SVHC (15-Jan-2018)
- Approvals & Standards: VDE
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 8A
- Contact Voltage AC Nom: 277V
- Contact Voltage DC Nom: 30V
- External Depth: 18.2mm
- External Height: 14.7mm
- External Width: 10.2mm
- Nom Operating Power: 200mW
- Relay Type: Power
