Pc/HV/S/WF 10nF 1.5kV Cap, 0.01µF, 1.5 kV, 20%, PP LCR Components

LCR COMPONENTSSKU:PC/HV/S/WF 10NF 1.5KV Bestelcode:9520376

Prijs:
Actie prijs€3,73

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1969 units)

Documenten en downloads

Omschrijving

LCR COMPONENTS - PC/HV/S/WF 10NF 1.5KV - Power Film Capacitor, Metallized PP, Axial Leaded, 0.01 µF, ± 20%, High Frequency, Through Hole

  • Capacitance: 10000pF
  • Voltage Rating: 1.5kV
  • Capacitor Dielectric Type: PP (Polypropylene)
  • Capacitance Tolerance: ± 20%
  • Product Range: PC/HV/S/WF Series
  • Capacitor Case Style: -
  • Capacitor Terminals: Axial Leaded
  • Lead Spacing: -
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 100°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Body Diameter: 10mm
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Mounting: Through Hole
  • Climatic Category: 40/85/56
  • External Length / Height: 28mm
  • Height: 28mm
  • Insulation Resistance: 100000Mohm
  • Lead Length: 40mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +100°C
  • Power Factor: 0.0005
  • Power Factor Frequency: 1kHz
  • Pulse Rating: 2000V/µs
  • Temperature Coeff. -: -200ppm/°C
  • Temperature Coefficient: -200ppm/°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 1.5kV
  • Voltage Rating VAC: 450V
