SCHRACK - TE CONNECTIVITY - 1393219-6 - General Purpose Relay, PE Series, Power, Non Latching, SPDT, 12 VDC, 5 A
- Contact Configuration: SPDT
- Coil Voltage: 12VDC
- Contact Current: 5A
- Product Range: PE Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 240VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 685ohm
- SVHC: No SVHC (15-Jan-2018)
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 5A
- Contact Voltage AC Nom: 250V
- External Depth: 10mm
- External Height: 10mm
- External Width: 20mm
- Nom Operating Power: 210mW
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Time: 8ms
- Relay Type: Power - General Purpose
- Release Time: 8ms
