Omschrijving
VISHAY - PRV4F0GJS102KAB10 - Rotary Potentiometer, Industrial, 1 kohm, 1 Turns, Linear, 2 W, ± 20%, PRV4
- Track Resistance: 1kohm
- No. of Turns: 1Turns
- Track Taper: Linear
- Power Rating: 2W
- Resistance Tolerance: ± 20%
- Product Range: PRV4 Series
- Potentiometer Mounting: Bushing
- Shaft Diameter: 6.35mm
- No. of Gangs: 1
- Adjustment Type: Screwdriver Slot
- Shaft Length: 22.2mm
- Contact Resistance Variation +: 1%
- Contact Resistance Variation -: 1%
- Electrical Angular Rotation Tolerance +: 10°
- Electrical Angular Rotation Tolerance -: 10°
- End Resistance: 4ohm
- External Length / Height: 12mm
- IP / NEMA Rating: IP67
- Insulation Resistance: 100000Mohm
- Mechanical Angular Rotation Tolerance +: 5°
- Mechanical Angular Rotation Tolerance -: 5°
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +125°C
- Proof Voltage: 1500V
- Resistor Element Material: Cermet
- Rotation Electrical Angle: 270°
- Rotation Mechanical Angle: 300°
- Temperature Coefficient: ± 200ppm/°C
- Voltage Rating: 500V
