AMPHENOL INDUSTRIAL - PT02E22-36SX - Circular Connector, Miniature, Bayonet, Solder, Box Mount Receptacle, 36 Contacts, Solder Socket
- Product Range: -
- Circular Connector Shell Style: Box Mount Receptacle
- No. of Contacts: 36Contacts
- Circular Contact Type: Solder Socket
- Coupling Style: Bayonet
- Insert Arrangement: 22-36
- Connector Body Material: Aluminium Alloy Body
- Connector Body Plating: Olive Drab Chromate over Cadmium
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Insert Rotation: X
- Service Class: Environmentally Sealed
- Equivalent Military Specification: MIL-DTL-26482 Series I
- Approval Category: MIL-C-26482 Series I
