R-78HB15-0.5 DC-DC Converter, 15V, 0.5A RECOM Power

RECOM POWER - R-78HB15-0.5 - DC/DC Converter, ITE, 1 Output, 7.5 W, 15 V, 500 mA, R-78HB Series

• No. of Outputs: 1 Output
• Output Power Max: 7.5W
• Output Voltage Nom.: 15V
• Output Current Max: 500mA
• DC / DC Converter Output Type: Fixed
• DC / DC Converter Mounting: Through Hole
• Input Voltage DC Min: 20V
• Input Voltage DC Max: 72V
• DC / DC Converter Type: SIP
• Depth: 11.5mm
• Width: 8.5mm
• Height: 17.5mm
• Product Range: -
• SVHC: No SVHC (15-Jan-2019)
• Efficiency Max: 96%
• External Depth: 17.5mm
• External Length / Height: 11.5mm
• External Width: 8.5mm
• Input Voltage Max: 72V
• Input Voltage Min: 20V
• No. of Outputs: 1Outputs
• Operating Temperature Max: +85°C
• Operating Temperature Min: -40°C
• Output Current: 500mA
