R13-527C-02-BB Switch, Push Button, SPST, Mom multicomp Pro

MULTICOMP PROSKU:R13-527C-02-BB Bestelcode:1634668

Prijs:
Actie prijs€5,18

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (5235 units)

Documenten en downloads

Omschrijving

MULTICOMP PRO - R13-527C-02-BB - Pushbutton Switch, 20.2 mm, SPST, Off-(On), Round Raised, Black

  • Switch Operation: Off-(On)
  • Contact Configuration: SPST
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Nom: -
  • Contact Current Max: 16A
  • Switch Terminals: Quick Connect
  • Product Range: -
  • Actuation Type: Round
  • Actuator / Cap Colour: Black
  • Approval Bodies: UL
  • Bezel Diameter: 23mm
  • Bezel Height: 2mm
  • Colour: Black
  • Contact Current AC: 6A
  • Contact Current AC Max: 16A
  • Contact Resistance: 50mohm
  • Contact Voltage VAC: 125V
  • Flammability Rating: UL 94V-2
  • Height: 14.5mm
  • Height Above Panel: 6.5mm
  • Illumination Colour: Non-illuminated
  • Insulation Resistance: 100Mohm
  • Insulation Resistance Voltage: 500VDC
  • Material: Nylon
  • Operating Temperature Max: 65°C
  • Operating Temperature Min: -20°C
  • Panel Cutout Diameter: 20.2mm
  • Panel Thickness Max: 3mm
  • Panel Thickness Min: 0.7mm
  • Pushbutton Actuator Style: Raised Round
  • Pushbutton Switch Type: Standard
  • Switch Mounting: Panel
  • Tab Width: 4.75mm
