R143405000 RF Coaxial, TNC, Straight Jack, 50ohm RADIALL

RADIALLSKU:R143405000 Bestelcode:4195619

Prijs:
Actie prijs€19,16

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (305 units)

Documenten en downloads

Omschrijving

RADIALL - R143405000 - RF / Coaxial Connector, TNC Coaxial, Straight Flanged Jack, Solder, 50 ohm, Beryllium Copper

  • Connector Type: TNC Coaxial
  • Connector Body Style: Straight Flanged Jack
  • Coaxial Termination: Solder
  • Impedance: 50ohm
  • Coaxial Cable Types: -
  • Contact Material: Beryllium Copper
  • Contact Plating: Gold Plated Contacts
  • Frequency Max: 11GHz
  • Connector Mounting: Panel Mount
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2018)
  • Connector Mounting Orientation: Panel
  • Insulation Resistance: 5000Mohm
  • Material: Brass
  • No. of Mating Cycles: 500
  • Operating Frequency Max: 11GHz
  • Operating Temperature Max: 165°C
  • Operating Temperature Min: -65°C
  • Termination Method: Solder
  • Voltage Rating VAC: 500V
  • Withstand Voltage: 1000V
