KEMET - R46KW510050M1K - Safety Capacitor, Metallized PP, Radial Box - 2 Pin, 10 µF, ± 10%, X2, Through Hole
- Capacitance: 10µF
- Suppression Class: X2
- Product Range: R46 275V Series
- Voltage Rating X: 275V
- Voltage Rating Y: -
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 10%
- dv/dt Rating: 100V/µs
- Capacitor Case Style: Radial Box
- Capacitor Terminals: Radial Leaded
- Operating Temperature Min: -40°C
- Operating Temperature Max: 110°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 10%
- Capacitor Application: General Purpose
- Capacitor Mounting: Through Hole
- External Depth: 30mm
- External Length / Height: 45mm
- External Width: 42mm
- Lead Length: 25mm
- Lead Spacing: 37.5mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +110°C
- Voltage Rating VAC: 275V
