VISHAY - RTOP200V10R0JB. - Resistor, Screw, 10 ohm, RTOP, 200 W, ± 5%, Screw, 1.5 kV
- Resistance: 10ohm
- Product Range: RTO Series
- Power Rating: 200W
- Resistance Tolerance: ± 5%
- Resistor Terminals: Screw
- Voltage Rating: 1.5kV
- Resistor Element Material: Thick Film
- Temperature Coefficient: ± 150ppm/°C
- Element Limiting Voltage: 1500V
- External Depth: 12.5mm
- External Length / Height: 38mm
- External Width: 25mm
- Fixing Centres: 30mm
- Fixing Hole Diameter: 4.2mm
- Full Power Rating Temperature: 25°C
- Insulation Resistance: 10000000Mohm
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +125°C
- Overload Capability: 2.5 x pr for 5 secs
- Power Rating with Heatsink: 200W
- Resistor Case Style: ISOTOP
- Resistor Mounting: Panel
- Temperature Coeff. +: 150ppm/°C
- Temperature Coeff. -: 150ppm/°C
- Thermal Resistance: 0.5°C/W
- Tolerance +: 5%
- Tolerance -: 5%
