Omschrijving
MENTOR - RTZ.2080G - Circuit Board Indicator, Green, 8 LEDs, Through Hole, 1.8mm, 20 mA, 10 mcd
- LED Colour: Green
- No. of LEDs: 8LEDs
- LED Mounting: Through Hole
- Bulb Size: 1.8mm
- Forward Current If: 20mA
- Luminous Intensity: 10mcd
- Forward Voltage: 2.2V
- Viewing Angle: 70°
- Height: 5.08mm
- Width: 20.32mm
- Product Range: -
- SVHC: No SVHC (15-Jan-2019)
- Display Size: 20.32mm x 5.08mm
- External Depth: 5.5mm
- External Length / Height: 20.32mm
- External Width: 5.08mm
- Forward Current If Max: 20mA
- Forward Voltage VF Max: 2.5V
- LED / Lamp Size: 1.8mm
- LED Configuration: Array
- LED Type: Standard
- Lead Length: 3.3mm
- Lead Spacing: 2.54mm
- Lens Shape: Round
- Luminous Intensity Min: 5mcd
- Luminous Intensity Typ: 10mcd
- No. of Pins: 16Pins
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +85°C
- Peak Wavelength: 568nm
- Reverse Protection Voltage: 5V
- Voltage Vf Typ: 2.2V
- Wavelength Typ: 568nm
