BOURNS - SDR0403-100ML - Power Inductor (SMD), 10 µH, 1.15 A, Unshielded, 1.7 A, SDR0403, 4.5mm x 4mm x 3.2mm
- Inductance: 10µH
- RMS Current (Irms): 1.15A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 1.7A
- Product Range: SDR0403 Series
- Power Inductor Case: 4.5mm x 4mm x 3.2mm
- DC Resistance Max: 0.18ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 4mm
- External Length / Height: 3.2mm
- External Width: 4.5mm
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 28
- Q Test Frequency: 2.52MHz
- Resonant Frequency: 33MHz
- Self Resonant Frequency Min: 33MHz
- Test Frequency: 2.52MHz
