Omschrijving
DATASENSOR - SR21-RG - Photoelectric Sensor, Slot, SR21 Series, Reflective, 7.5mm, NPN / PNP, 10 Vdc to 30Vdc
- Sensor Output: NPN / PNP
- Sensing Range Max: 7.5mm
- Supply Voltage DC Min: 10V
- Supply Voltage DC Max: 30V
- Output Current: 100mA
- Product Range: SR21 Series
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 26mm
- External Length / Height: 90mm
- External Width: 20mm
- IP / NEMA Rating: IP65
- Operating Temperature Max: 60°C
- Operating Temperature Min: -20°C
- Operating Temperature Range: -20°C to +60°C
- Output Current Max: 100mA
- Response Time: 20µs
- Sensor Input: Optical
- Slot Width: 2mm
- Supply Voltage Range DC: 10V to 30V
- Thread Size: M8
