Omschrijving
BOURNS - SRR1206-221KL - Power Inductor (SMD), 220 µH, 700 mA, Shielded, 12.7mm x 12.7mm x 6.5mm
- Inductance: 220µH
- RMS Current (Irms): 700mA
- Inductor Construction: Shielded
- Saturation Current (Isat): -
- Product Range: -
- Power Inductor Case: 12.7mm x 12.7mm x 6.5mm
- DC Resistance Max: 0.46ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 6.5mm
- External Length / Height: 12.7mm
- External Width: 12.7mm
- Inductor Type: Shielded Power Choke
- Operating Temperature Max: 125°C
- Operating Temperature Min: 40°C
- Resonant Frequency: 4MHz
- Self Resonant Frequency Min: 4MHz
- Test Frequency: 0.796MHz
