Omschrijving
BOURNS - SRR1208-680YL - Power Inductor (SMD), 68 µH, 1.8 A, Shielded, 2.6 A, 12.7mm x 12.7mm x 8.5mm
- Inductance: 68µH
- RMS Current (Irms): 1.8A
- Inductor Construction: Shielded
- Saturation Current (Isat): 2.6A
- Product Range: -
- Power Inductor Case: 12.7mm x 12.7mm x 8.5mm
- DC Resistance Max: 0.135ohm
- Inductance Tolerance: ± 15%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 8.5mm
- External Length / Height: 12.7mm
- External Width: 12.7mm
- Inductor Type: Shielded Power Choke
- Operating Temperature Max: 125°C
- Operating Temperature Min: 40°C
- Q Factor: 20
- Q Test Frequency: 2.52MHz
- Resonant Frequency: 15MHz
- Self Resonant Frequency Min: 5MHz
- Test Frequency: 2.52MHz
