TBU-CA085-200-WH High-Speed Protector Ic, 425VAC, SMD Bourns

BOURNS - TBU-CA085-200-WH - Surge Protector, High Speed Surge Protector IC, 1 Pole, 425 VAC, PCB - Surface Mount

• Product Range: TBU-CA Series
• Suppressor Type: High Speed Surge Protector IC
• No. of Outlets: -
• Outlet Type: -
• Voltage Rating: 850V
• Output Current: -
• Peak Surge Current: -
• Response Time: 1µs
• SVHC: No SVHC (15-Jan-2018)
• Continuing Operating Voltage Max: 425VAC
• External Depth: 4mm
• External Length / Height: 0.85mm
• External Width: 6.5mm
• No. of Poles: 1 Pole
• Operating Temperature Max: 125°C
• Operating Temperature Min: -40°C
• Resistance: 12.3ohm
• Suppressor Mounting: PCB - Surface Mount
• Surge Current: 300mA
