Omschrijving
TRACO POWER - TIM 3.5-4813SM - Isolated Surface Mount DC/DC Converter, Medical, 2:1, 3.5 W, 1 Output, 15 V, 234 mA
- No. of Outputs: 1 Output
- Output Power Max: 3.5W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 234mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TIM 3.5SM Series
- Input Voltage DC Min: 36V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Surface Mount Device
- Width: 14.4mm
- Height: 10.5mm
- Depth: 24.3mm
- SVHC: No SVHC (27-Jun-2018)
- Approvals & Standards: EN, ES, IEC
