UPM1A222MHD Cap, 2200µF, 10V, 20% NICHICON

NICHICONSKU:UPM1A222MHD Bestelcode:8812403

Prijs:
Actie prijs€2,31

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (62 units)

Documenten en downloads

Omschrijving

NICHICON - UPM1A222MHD - Electrolytic Capacitor, 2200 µF, 10 V, ± 20%, Radial Leaded, 5000 hours @ 105°C, Polar

  • Capacitance: 2200µF
  • Voltage Rating: 10V
  • Product Range: PM Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 12.5mm
  • Lead Spacing: 5mm
  • Height: 25mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 5000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 25mm
  • Impedance: 0.043ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • No. of Pins: 2Pins
  • Operating Life Temperature: 105°C
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 5000h
  • Ripple Current AC: 1320mA
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 10V
