Omschrijving
TE CONNECTIVITY - V23134B0052C642 - Automotive Relay, 12 VDC, 40 A, SPST-NO, Plug In, Quick Connect, Power Relay F4
- Coil Voltage: 12VDC
- Contact Current: 40A
- Contact Configuration: SPST-NO
- Relay Mounting: Through Hole
- Relay Terminals: Solder
- Product Range: Power Relay F4 Series
- Contact Voltage DC Nom: 12V
- Coil Resistance: 90ohm
- Contact Material: Silver
- SVHC: No SVHC (12-Jan-2017)
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 60A
- External Depth: 25.9mm
- External Height: 24.9mm
- External Width: 25.9mm
