BLOCK - VB2.8/2/12 - PCB Transformer, PCB, Encapsulated Safety Isolating, 230V, 2 x 12V, 2.8 VA, 50Hz / 60Hz
- Power Rating: 2.8VA
- Secondary Voltages: 2 x 12V
- Current Rating: 117mA
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- External Depth: 34mm
- External Length / Height: 32.3mm
- External Width: 27.3mm
- Hole Spacing - Length: 20mm
- Output Voltage: 12V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 20mm
- Primary Voltages: 1 x 230V
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
- Test Voltage: 5kV
- Weight: 140g
