TT ELECTRONICS / WELWYN - W22-180RJI - Through Hole Resistor, 180 ohm, W22, 7 W, ± 5%, Axial Leaded, 200 V
- Resistance: 180ohm
- Product Range: W22 Series
- Power Rating: 7W
- Resistance Tolerance: ± 5%
- Resistor Case Style: Axial Leaded
- Voltage Rating: 200V
- Resistor Element Material: Wirewound
- Temperature Coefficient: ± 75ppm/°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 8mm
- External Length / Height: 22mm
- Full Power Rating Temperature: 70°C
- Lead Diameter: 0.8mm
- Lead Length: 23.1mm
- No. of Pins: 2Pins
- Operating Temperature Max: 350°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +350°C
- Resistor Mounting: Through Hole
- Temperature Coeff. +: 75ppm/°C
- Temperature Coeff. -: 75ppm/°C
- Tolerance +: 5%
- Tolerance -: 5%
- Voltage Rating V DC: 200V
