Z-15GK355-B Microswitch, Z, Plunger Omron

OMRONSKU:Z-15GK355-B Bestelcode:1181276

Prijs:
Actie prijs€33,04

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (202 units)

Documenten en downloads

Omschrijving

OMRON - Z-15GK355-B - Microswitch, Snap Action, Plunger, SPDT, Screw, 15 A, 250 VDC

  • Microswitch Type: Snap Action
  • Microswitch Actuator: Plunger
  • Contact Configuration: SPDT
  • Switch Terminals: Screw
  • Contact Current Max: 15A
  • Contact Voltage DC Nom: 250VDC
  • Product Range: Z Series
  • Contact Voltage AC Nom: 250VAC
  • Operating Force Max: 540gf
  • Actuation Type: Plunger
  • Actuator Type: Plunger
  • Contact Current AC: 15A
  • Contact Current AC Max: 15A
  • Contact Current DC Max: 15A
  • Contact Voltage AC Max: 240V
  • Contact Voltage DC Max: 250V
  • Differential Travel Max: 0.06mm
  • External Depth: 49.2mm
  • External Length / Height: 21.4mm
  • External Width: 17.5mm
  • Fixing Centres LxW: 25mm
  • No. of Electrical Operations: 700000
  • No. of Mechanical Operations: 10000000
  • Operating Force: 5.3N
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -25°C
  • Over Travel Min: 3.5mm
  • Pre-travel: 2.4mm
  • Release Force: 114gf
  • Switch Operation: Off-On
